Fence Bending Machine

General Description of hydraulic bending machine:

This hydraulic bending machine has seven machine models: 40t, 63t, 80t, 100t, 125t, 160t, 200t, which adopt the popular structure internationally and the complete machine has a good rigidity, beautiful appearance, advanced technology as well as reliable functions, being one of the ideal plate forming devices. The mesh bending machine has high production efficiency and a durable service, which is extensively employed in various industries, such as aircraft, motorcar, shipbuilding, electrical appliance machinery and light industry.

Detailed Description of hydraulic bending machine:

The mesh bending machine body is composed of right and left wallboards, working table, oil cylinder, slider and oil tank. The oil tank is placed in the center surface of the wallboards with a reasonable pressing force and enough strength and rigidity, and transportation, installation and commissioning are all convenient and easy. In addition, the bending machine employs mechanical synchronous system and could bear a certain torque. The hydraulic bending machine is easily operated and has the functions of inching, single and continuous travelling, and the pressure maintaining time could be adjusted. The various norms and safety performance of the complete machine all conform to the national standards.

The bending machine has upper mould adjusting mechanism, which could help get high bending precision. And it could be also used for pipe bending and piercing if it is equipped with the corresponding devices in the production process.

When bending plates with different thickness, this bending machine should elect V-shape groove lower mould with different openings (if equipped with upper and lower mould with different shapes, then workpieces with various shapes could be bent), at the same time the bending force values could be calculated with the plate bending force figure, and adjust the corresponding working oil pressure according to the value (indicated by the pressure gauge), then the required bending force could be promised.
